	<item>
		<title>テープレコーダー用 小型ピンチローラー</title>
		<link>https://www.nakajima-roller.jp/small-pinch-roller-for-tape-recorders/</link>
					<comments>https://www.nakajima-roller.jp/small-pinch-roller-for-tape-recorders/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Thu, 05 Mar 2026 23:30:00 +0000</pubDate>
				<category><![CDATA[ゴムローラー巻替え]]></category>
		<category><![CDATA[芯金製作+ゴム加工]]></category>
		<category><![CDATA[製品紹介]]></category>
		<category><![CDATA[ウレタン]]></category>
		<category><![CDATA[ゴムローラー]]></category>
		<category><![CDATA[ピンチロール]]></category>
		<category><![CDATA[工業用]]></category>
		<category><![CDATA[特注品]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6293</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2.jpg" class="webfeedsFeaturedVisual" /></p>テープレコーダー用 小型ピンチローラー 業務用テープレコーダー用ピンチロールが劣化し、ウレタンゴム巻きのお問い合わせを頂戴しました。 オリジナル・純正品は海外製だそうですが、当社では国内の工場でウレタン加工をし、ご提供さ [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2.jpg" alt="" class="wp-image-6301" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/02/small-pinch-roller-for-tape-recorders-2-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ウレタン材質の小型ピンチローラー</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>小型のピンチロールの発注先をお求めの方</li>



<li>1点からピンチロールを注文できる企業をお探しの方</li>



<li>レコーダー部品の製作実績を確認されたい方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">テープレコーダー用 小型ピンチローラー</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>業務用テープレコーダー用ピンチロールが劣化し、ウレタンゴム巻きのお問い合わせを頂戴しました。</p>



<p>オリジナル・純正品は海外製だそうですが、当社では国内の工場でウレタン加工をし、ご提供させていただきました。</p>



<p>非常に小さい部品ですが、当社ではまずはテストをしていただきたく1点から対応可能です。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>業務用テープレコーダーのピンチローラーを再生していただきたく問い合わせました。現状使用品はピンチローラーのゴム部分が経年劣化によりひび割れ等で剥離してしまっています。。。<br>材質はウレタンで指定したいです。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知しました。<br>サイズやウレタン硬度をご指定いただけますと幸いです。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>ちなみに今使用しているゴムローラーの硬度が分かりません。<br>見本を送りますので、調べてご提案いただくことはできますか？<br>ウレタンゴムを巻いてもらう芯金も支給します。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>ありがとうございます。<br>それでは、中古ローラーを荷受けしましたら、硬度は見本品を測定して近い硬度をご提案させていただきます。<br><br>なお芯金に部品が付属しておりましたら、外してお送り下さいませ。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「 テープレコーダー用ピンチローラー 」</strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1.jpg" alt="" class="wp-image-6302" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：仕上径φ21mm×芯径φ18×ゴム幅8mm L</li>



<li>材質：ウレタン</li>



<li>硬度：80度</li>



<li>芯金部はお客様よりご支給</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様から見本となるウレタンローラーを当社に送っていただき、そのウレタンローラーの硬度を計測し、同等の製品を製造させていただきました。</p>



<figure class="wp-block-image size-full is-style-default"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-5.jpg" alt="" class="wp-image-6303" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-5.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-5-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-5-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">送っていただいた見本品</figcaption></figure>



<p>見本品を計測したところ、約70度程度でしたので、ウレタンゴム70度にてご提案をいたしました。</p>



<p>上の写真では芯金に「固定リング」と「ベアリング」が内蔵されていますが、ウレタン加工時に部品を損傷させてしまう恐れがあるため、部品は外して・お客様の元で保管をお願いしております。</p>



<p class="is-style-icon_book">ピンチロールや搬送ロールなどは硬度70度程度の実績が多いです。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">ウレタン巻き ビフォーアフター</h4>



<p>傷がなくなり、表面がきれいな状態になりました。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-4.jpg" alt="" class="wp-image-6304" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-4.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-4-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-4-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ウレタン加工「前」</figcaption></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-1.jpg" alt="" class="wp-image-6305" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-1-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ウレタン加工「後」</figcaption></figure>
</div>
</div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">製作納期</h4>



<p>約3週間程度の期間を頂戴しました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">納品後のお客様の声</h4>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-3-300x225.jpg" alt="" class="wp-image-6306" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-3-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-3-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/small-pinch-roller-for-tape-recorders-3.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /></figure>


<p>商品の寸法、硬さ、密着度等大変良く、十分な性能が出ておりました。 <br><br>特にテープの巻取り精度が向上し、全く段差無く巻き取れる様になりました。 <br><br>恐らく、海外製オリジナルローラーと比較して密着度と真円度が向上し た物と思われます。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>

<p>この度は、ご注文ありがとうございました。<br>お役立ちでき、大変光栄です。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">ゴム巻きが必要な中古ローラーを送っていただく</h3>



<h4 class="wp-block-heading">硬度が分からなければ当社で測定致します</h4>



<p>お客様からお送りいただいたゴムローラーのゴム材質に硬度計を当てて、硬度を測定し、同程度の硬度でゴム巻き替えを実施することが可能です。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2013/05/rubber-roller-hardness-2-300x225.jpg" alt="" class="wp-image-2506" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2013/05/rubber-roller-hardness-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2013/05/rubber-roller-hardness-2-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2013/05/rubber-roller-hardness-2.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /><figcaption class="wp-element-caption">硬度計で計測</figcaption></figure>
</div>
</div>



<p class="is-style-icon_pen">中古ロールをご発送の際、当社での荷受けは土日祝日でも可能なため、お客様のご都合が良いタイミングで発送下さい。</p>



<p class="is-style-big_icon_memo"><span class="swl-marker mark_yellow">ご利用用途から最適な硬度をご提案することも可能</span>ですので、お問合せの際は、情報を頂戴できますと幸いです。</p>



<h4 class="wp-block-heading">芯金から複製も可能</h4>



<p>もし中古ロールが1本しかなく、同じロール2本用意したい場合は、複製することも可能です。</p>



<p class="is-style-icon_announce">芯金の形状が複雑でなければ見本となる中古ロールから図面を作成し、複製が可能です。<br>芯金部の金属指定がない場合は、近い材質でご提案となります。</p>



<h4 class="wp-block-heading">付属部品は取り外して発送ください</h4>



<p>ゴムローラーに付属しているベアリングやシャフトなど部品がございましたら、お客様の下で取り外して保管をお願い致します。<br><br>取り付けたままゴム巻きをしますと加工時に部品を劣化・損傷させてしまう恐れがございます。</p>



<p class="is-style-icon_info">部品を当社で取り外し・組立・保管することも可能です。<br>その場合、別途、分解・組立手数料などを頂戴する場合がございますので、ご了承下さい。</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/small-pinch-roller-for-tape-recorders/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>【研磨機械 パッド圧着用途】高重量の三つ持ち手ハンドローラーで気泡抜き</title>
		<link>https://www.nakajima-roller.jp/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles/</link>
					<comments>https://www.nakajima-roller.jp/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Wed, 04 Mar 2026 23:30:00 +0000</pubDate>
				<category><![CDATA[【特注】ハンドローラー]]></category>
		<category><![CDATA[【特注】長柄付きローラー]]></category>
		<category><![CDATA[特注品]]></category>
		<category><![CDATA[製品紹介]]></category>
		<category><![CDATA[NBR]]></category>
		<category><![CDATA[ゴムローラー]]></category>
		<category><![CDATA[圧着]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6275</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg" class="webfeedsFeaturedVisual" /></p>【研磨機械 パッド圧着用途】高重量の三つ持ち手ハンドローラーで気泡抜き 沖縄のお客様から、大型のゴムローラー特注製作のご依頼をいただきました。 用途は研磨機のパッドを圧着し、気泡を効率良く抜きたいとのことでした。 ゴムロ [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg" alt="" class="wp-image-6298" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>5kg以上の重量があるゴムローラーで特定の媒体の圧着をご検討の方</li>



<li>ネット通販の規格品では購入できない1点物の特注品をお求めの方</li>



<li>ご利用の用途に応じてゴムローラー製品の仕様をご相談されたい方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">【研磨機械 パッド圧着用途】高重量の三つ持ち手ハンドローラーで気泡抜き</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>沖縄のお客様から、大型のゴムローラー特注製作のご依頼をいただきました。</p>



<p>用途は研磨機のパッドを圧着し、気泡を効率良く抜きたいとのことでした。</p>



<p>ゴムローラーの自重を活かして圧着作業をしたいため重量は5kg以上は欲しいとのご要望がございました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>研磨の機械の定盤にパッド（粘着付き）を貼り付けるときに、手で気泡が入らないように貼り付けていて手間がかかります。<br>圧着用ゴムローラーを特注製作してパッド貼り付け向けに使用したいです。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知致しました。<br>ご希望のサイズをお伺いします。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>・ローラー幅950㎜<br>・ローラー単体の重さ5kg理想<br>・ローラー径は、8～11㎝程度<br>を希望します。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>ありがとうございます。<br>それでは、お時間をいただき設計を進めてい参ります。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「&nbsp;小型ウレタンローラー ヘリカル溝加工付き 」</strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg" alt="" class="wp-image-6298" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：仕上径φ84mm×芯径φ60×ゴム幅950mm L</li>



<li>材質：NBR</li>



<li>硬度：20度</li>



<li>芯金：A5056材</li>



<li>持ち部分：：パイプ材</li>



<li>持ち手と枠部の塗装：白メラミン塗装</li>



<li>ゴムローラー部の重量：5.2kg</li>



<li>全体重量：9.2kg</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様から指定があった寸法と重量で設計・製造させていただきました。</p>



<p>持ち手が３つ付いているのが特徴的で、持ち手部を取り外し可能。</p>



<p>ゴムローラーも枠部から取り外すことが可能です。</p>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-2.jpg" alt="" class="wp-image-6299" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-2.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2026/03/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles-2-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">遠方への発送</h4>



<p>本件は沖縄県のお客様の工場へ、東京都にある当社から発送いたしました。</p>



<p>持ち手やゴムローラーが分解できる設計のため、梱包も組立時よりコンパクトにでき送料も抑えることができました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">製作納期</h4>



<p>製作期間1.5ヵ月～2ヵ月程度</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/heavy-duty-three-handled-hand-roller-for-pad-pressing-and-removing-air-bubbles/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>123クリーナー 1L タイプ ばら売り 販売終了のご連絡</title>
		<link>https://www.nakajima-roller.jp/end-of-sales-announcement/</link>
					<comments>https://www.nakajima-roller.jp/end-of-sales-announcement/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Sun, 07 Dec 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[お知らせ]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6284</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/12/end-of-sales-announcement-1.jpg" class="webfeedsFeaturedVisual" /></p>123クリーナー 1L タイプ ばら売り 販売終了のご連絡 この度は、ゴムローラー洗浄剤「123クリーナー」 1L タイプの1本単位での販売を終了させていただくことになりましたので、お知らせ致します。 2025年12月以 [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/12/end-of-sales-announcement-1.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="640" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/12/end-of-sales-announcement-1.jpg" alt="" class="wp-image-6286" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/12/end-of-sales-announcement-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/12/end-of-sales-announcement-1-300x300.jpg 300w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<h2 class="wp-block-heading">123クリーナー 1L タイプ ばら売り 販売終了のご連絡</h2>



<p>この度は、ゴムローラー洗浄剤「123クリーナー」 1L タイプの1本単位での販売を終了させていただくことになりましたので、お知らせ致します。</p>



<p>2025年12月以降にご購入をご希望のお客様は恐れ入りますが、<br>・最少ロット 12本入り＝1箱<br>・一斗缶 18L 品<br>のどちらかでの購入をご検討いただけますと幸いです。</p>



<p class="is-style-big_icon_memo">「12本入り＝1箱」品・「一斗缶」品はメーカーより直送の製品となりますので、別途メーカー直送送料を頂戴致します。</p>



<p>ご注文は下記サイトよりお願い致します。</p>



<h3 class="wp-block-heading">ご注文方法</h3>



<p>当社ECカート販売サイトの商品ページからご注文いただくことも可能です。</p>



<p>下記のURLリンクより、アクセスいただけます。</p>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl"><span><strong>ご注文は下記のURLリンクよりどうぞ</strong></span></div><div class="cap_box_content">
<p><a href="https://nakajima-roller.shop-pro.jp/?pid=148583102">https://nakajima-roller.shop-pro.jp/?pid=148583102</a></p>
</div></div>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/end-of-sales-announcement/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>2025-2026年 年末年始休業のお知らせ</title>
		<link>https://www.nakajima-roller.jp/year-end-and-new-year-holidays/</link>
					<comments>https://www.nakajima-roller.jp/year-end-and-new-year-holidays/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Sun, 30 Nov 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[お知らせ]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=4155</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2022/12/year-end-and-new-year-holidays-2022-2023-eye.jpg" class="webfeedsFeaturedVisual" /></p>平素は格別のご愛顧を賜り、厚く御礼申し上げます。 誠に勝手ながら、下記の期間を年末年始の休業とさせていただきます。 お客様にはご不便をお掛けすることと存じますが、何卒ご了承くださいますようお願い申し上げます。 年末年始  [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2022/12/year-end-and-new-year-holidays-2022-2023-eye.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image is-style-st-photohu"><img decoding="async" width="640" height="427" src="https://www.nakajima-roller.jp/wp-content/uploads/2022/12/year-end-and-new-year-holidays-2022-2023.jpg" alt="2022年も、ありがとうございました。" class="wp-image-4160" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2022/12/year-end-and-new-year-holidays-2022-2023.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2022/12/year-end-and-new-year-holidays-2022-2023-300x200.jpg 300w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">2024年も、ありがとうございました。</figcaption></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>平素は格別のご愛顧を賜り、厚く御礼申し上げます。</p>



<p>誠に勝手ながら、下記の期間を年末年始の休業とさせていただきます。</p>



<p>お客様にはご不便をお掛けすることと存じますが、何卒ご了承くださいますようお願い申し上げます。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading"><strong>年末年始 休業期間</strong></h3>



<p class="has-border -border02">2025年12月27日（土） ～ 2025年1月4日（日） </p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>2025年1月5日（月）より通常営業とさせていただきます。 新年も宜しくお願い申し上げます。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>2025年12月26日（金）の営業終了後（17時半以降）のお問い合わせについては2026年1月5日（月）より順次対応させていただきます。</p>



<p>(メールやSNSのメッセージにて、お問い合わせいただいた場合、可能な限りは上記休業期間中でも返信をさせていただきます。)</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center is-style-balloon_box2 has-border -border01">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/year-end-and-new-year-holidays/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>【ブリードレス粘着材質】ウレタン系 特殊樹脂クリーナーローラー</title>
		<link>https://www.nakajima-roller.jp/bleedless-adhesive-material-cleaner-roller/</link>
					<comments>https://www.nakajima-roller.jp/bleedless-adhesive-material-cleaner-roller/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Wed, 17 Sep 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[ゴムローラー巻替え]]></category>
		<category><![CDATA[材質]]></category>
		<category><![CDATA[特注品]]></category>
		<category><![CDATA[芯金製作+ゴム加工]]></category>
		<category><![CDATA[製品紹介]]></category>
		<category><![CDATA[ウレタン]]></category>
		<category><![CDATA[ゴミ取りローラー]]></category>
		<category><![CDATA[ゴムローラー]]></category>
		<category><![CDATA[樹脂]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6259</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1.jpg" class="webfeedsFeaturedVisual" /></p>【ブリードレス粘着材質】クリーナーローラー 粘着ゴム材質をコーティングした装置を試作したいというお客様よりお問合せをいただきました。 まずはローラーの形状で実験・試験をしたいとの事で、芯金作成・粘着材質成形したロール製品 [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1.jpg" alt="" class="wp-image-6260" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">綺麗なグリーンカラーの粘着ブリードレスゴムローラー</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>粘着ゴム材質クリーナーロール製造をご検討中の方</li>



<li>ブリードレスタイプのゴム材質をお探しの方</li>



<li>粘着ゴムタイプで特に柔らかい材質をお求めの方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">【ブリードレス粘着材質】クリーナーローラー</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>粘着ゴム材質をコーティングした装置を試作したいというお客様よりお問合せをいただきました。</p>



<p>まずはローラーの形状で実験・試験をしたいとの事で、芯金作成・粘着材質成形したロール製品をご提案させていただきました。</p>



<p>できるだけ粘着材質で柔らかい硬度かつ、シリカを含んでいない、ブリードが発生しないなどの諸条件を求められる案件でした。</p>



<p>本記事では、そんな条件をクリアできるような<span class="swl-marker mark_yellow">特殊樹脂粘着材質のローラー</span>をご紹介致します。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>ごみ取り用のローラーを検討しています。<br>以前、あるシリコン製のものを使用してパネルなどの表面に付着した異物の除去をおこなったところ、 接触したパネル表面にオイルのような残留物がありました。 <br>一般的なシリコン製のローラーは表面に抽出物が出るのでしょうか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>シリコンゴムは使用していくとシリカなどを含む抽出物が発生するリスクがある材質です。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>硬度A10～A20程度のゴミ取りローラーを検討しているのですが、抽出物発生リスクが少ない材質でご提案いただけないでしょうか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知致しました。<br>特殊樹脂材質で粘着性があり硬度も14度程度の材質をロールとしてご提案可能です。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「&nbsp;ブリードレス粘着材質 クリーナーローラー 」</strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-4.jpg" alt="" class="wp-image-6263" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-4.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-4-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-4-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：仕上径φ40mm×芯径φ10×ゴム幅300mm L</li>



<li>材質：ブリードレス特殊樹脂 粘着タイプ (ウレタン系)</li>



<li>硬度：14度</li>



<li>芯金から製作：SS材 ムク芯 φ10×400mm</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>お客様のご要望ポイント</span></div><div class="cap_box_content">
<ul class="wp-block-list is-style-check_list -list-under-dashed">
<li>シリカを含んでいない</li>



<li>ブリードと呼ばれる油分など抽出物が発生しない材質</li>



<li>硬度10～20度程度の軟質材質</li>



<li>ゴム材質表面に粘着性がありゴミ取り機能を持たせる</li>
</ul>
</div></div>



<p>お客様から上記4つのご要望をいただき、クリアできる材質である「ブリードレス特殊樹脂材質」をご提案しました。</p>



<p class="is-style-icon_book">「ブリードレス特殊樹脂材質ロール」製作可能なロール幅　<br>→全長２０００mmＬまで対応可能です。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">芯金から製作</h4>



<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-3-1-300x225.jpg" alt="" class="wp-image-6269" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-3-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-3-1-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-3-1.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /></figure>



<p>本件は芯金から製作を担当させていただきました。</p>



<p>芯金の直径がφ10mmで樹脂ロール部直径がφ40mmのため片肉厚が1.5mmございます。</p>



<h4 class="wp-block-heading">製作納期</h4>



<p>芯金製作+樹脂ロール成型で、合計 約2ヵ月程度の期間を頂戴しました。</p>



<h4 class="wp-block-heading">お手入れ方法</h4>



<p>ゴミ取りロールとしてご利用後に、水拭きをすればゴミ落とし+粘着性再生が可能です。</p>



<p class="is-style-icon_pen">ウレタン系樹脂は水に弱いですが、一時的な洗浄での使用+洗浄後しっかり拭き上げれば劣化は抑えることができます。なお専用のクリーナー製品もご用意がございます。</p>



<h3 class="wp-block-heading">ハンドロールとして製造・提供可能</h3>



<h4 class="wp-block-heading">ハンドローラータイプも特注対応</h4>



<p>必要であれば、お客様からサイズをご指定いただき、ハンドローラータイプとしても製造・提供が可能です。<br>ご注文を1点からお受け致します。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-7-1.jpg" alt="" class="wp-image-6270" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-7-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-7-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-7-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">粘着性 特殊樹脂材質のハンドローラー</figcaption></figure>
</div>
</div>



<p class="is-style-icon_pen">ハンドローラータイプの場合、規格品の持ち手枠を採用するとコストカット可能です。<br>規格品「ゴム手ローラー」のラインナップは下のリンクよりご覧下さい。</p>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2020/10/rubber-hand-roller-300x300.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-hand-roller/">ゴム手ローラー | ハンドローラー製品</a>
						<span class="p-blogCard__excerpt">版画用・工業用幅3cm～60cmまで全品在庫あり ゴム手ローラー | ハンドローラー製品 「ゴム手ローラー」は片手持ちで使用するハンドローラー製品です。 ゴムロール幅が3c&#8230;</span>					</div>
				</div>
			</div>
		</div>


<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-6-1.jpg" alt="" class="wp-image-6271" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-6-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-6-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/bleedless-adhesive-material-cleaner-roller-6-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ハンドローラー用の粘着特殊樹脂材質ロール</figcaption></figure>



<p class="is-style-big_icon_memo">ソフトな特殊ゴム弾性体で、凹凸面にまでフィット可能な材質です。</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/bleedless-adhesive-material-cleaner-roller/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>ラッピングロール機 シリコンガイドローラー 巻替え</title>
		<link>https://www.nakajima-roller.jp/wrapping-roll-machine-silicone-guide-roller-rewinding/</link>
					<comments>https://www.nakajima-roller.jp/wrapping-roll-machine-silicone-guide-roller-rewinding/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Tue, 09 Sep 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[ゴムローラー巻替え]]></category>
		<category><![CDATA[特注品]]></category>
		<category><![CDATA[製品紹介]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6244</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1.jpg" class="webfeedsFeaturedVisual" /></p>ラッピングロール機 シリコンガイドローラー 巻替え 日頃、工場でラッピングロール機を稼働させているユーザー様から、シリコンゴムローラー巻き替え依頼をいただきました。 当社では、お客様のご用途にマッチしたゴム材質・ゴム硬度 [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1.jpg" alt="" class="wp-image-6245" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">シリコン材質のガイドローラー</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>シリコンゴムローラーの巻替えをご検討中の方</li>



<li>ゴムローラー巻き替えの事例・写真を確認したい方</li>



<li>近隣にゴムローラー発注先がなく、お困りの方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">ラッピングロール機 シリコンガイドローラー 巻替え</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>日頃、工場でラッピングロール機を稼働させているユーザー様から、シリコンゴムローラー巻き替え依頼をいただきました。</p>



<p>当社では、お客様のご用途にマッチしたゴム材質・ゴム硬度をご提案し、ゴムローラー巻き替えを1点からお受けしております。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>下の写真のように使用しているシリコン材質ガイドローラーの表面に傷が付いてしまいました。巻替えは可能でしょうか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-2-300x225.jpg" alt="" class="wp-image-6246" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-2-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-2.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知致しました。<br>巻替えが必要な中古ロールを当社にお送りいただくことは可能ですか？<br>できればベアリングなどの部品は貴社にて取り外し・保管をお願いします。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>ちなみに今使用しているゴムローラーの硬度が分かりません。<br>調べてご提案いただくことはできますか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>ありがとうございます。<br>それでは、中古ローラーを荷受けしましたら、硬度は中古品を測定して近い硬度をご提案させていただきます。<br>またガイドローラーのご利用用途で実績が多い硬度もお知らせ・ご提案致します。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「&nbsp;ラッピングロール機 シリコンガイドローラー 」</strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-3.jpg" alt="" class="wp-image-6247" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-3.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-3-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-3-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：仕上径φ64mm×芯径φ44×ゴム幅330mm L</li>



<li>材質：シリコン</li>



<li>硬度：70度</li>



<li>ゴム巻き替え (中古ローラーはユーザー様から支給)</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様からゴム巻替えが必要な中古ローラーを当社に送っていただき、そのゴムローラーを新しくゴム巻きしました。</p>



<p>ガイドパスローラーの製作実績としては硬度70度本をご提供することが多く、見本となった中古品ロールも70度付近だったため、70度のシリコン材質にてご提案させていただきました。</p>



<p class="is-style-icon_book">硬度は数字が大きいほど硬いという意です。<br>印刷用途の案件では、30度程度が多いため70度だと硬度が高く硬めです。<br>工業用系では50度以上の硬度が多く活用されます。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">ゴム巻替え ビフォーアフター</h4>



<p>傷がなくなり、表面がきれいな状態になりました。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-4.jpg" alt="" class="wp-image-6248" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-4.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-4-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-4-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「前」</figcaption></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-5.jpg" alt="" class="wp-image-6249" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-5.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-5-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-5-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「後」</figcaption></figure>
</div>
</div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">製作納期</h4>



<p>ゴム巻替えで約1ヵ月程度の期間を頂戴しました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">ゴム巻きが必要な中古ローラーを送っていただく</h3>



<h4 class="wp-block-heading">硬度が分からなければ当社で測定致します</h4>



<p>お客様からお送りいただいたゴムローラーのゴム材質に硬度計を当てて、硬度を測定し、同程度の硬度でゴム巻き替えを実施することが可能です。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-6-300x225.jpg" alt="" class="wp-image-6250" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-6-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-6-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/wrapping-roll-machine-silicone-guide-roller-rewinding-6.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /><figcaption class="wp-element-caption">支給いただいた中古ロール</figcaption></figure>
</div>
</div>



<p class="is-style-icon_pen">中古ロールをご発送の際、当社での荷受けは土日祝日でも可能なため、お客様のご都合が良いタイミングで発送下さい。</p>



<p class="is-style-big_icon_memo"><span class="swl-marker mark_yellow">ご利用用途から最適な硬度をご提案することも可能</span>ですので、お問合せの際は、情報を頂戴できますと幸いです。</p>



<h4 class="wp-block-heading">芯金から複製も可能</h4>



<p>もし中古ロールが1本しかなく、同じロール2本用意したい場合は、複製することも可能です。</p>



<p>上記の場合、中古ロール1本は巻替え・もう1本は中古ロールと同じように芯金を複製し+ゴム巻きを致します。</p>



<p class="is-style-icon_announce">芯金の形状が複雑でなければ見本となる中古ロールから図面を作成し、複製が可能です。<br>芯金部の金属指定がない場合は、近い材質でご提案となります。</p>



<h4 class="wp-block-heading">付属部品は取り外して発送ください</h4>



<p>ゴムローラーに付属しているベアリングやシャフトなど部品がございましたら、お客様の下で取り外して保管をお願い致します。<br><br>取り付けたままゴム巻きをしますと加工時に部品を劣化・損傷させてしまう恐れがございます。</p>



<p class="is-style-icon_info">部品を当社で取り外し・組立・保管することも可能です。<br>その場合、別途、分解・組立手数料などを頂戴する場合がございますので、ご了承下さい。</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/wrapping-roll-machine-silicone-guide-roller-rewinding/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>【ヘリカル溝加工付き】小型ウレタンローラー</title>
		<link>https://www.nakajima-roller.jp/small-urethane-roller-with-helical-grooves/</link>
					<comments>https://www.nakajima-roller.jp/small-urethane-roller-with-helical-grooves/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Sat, 06 Sep 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[ゴムローラー巻替え]]></category>
		<category><![CDATA[特注品]]></category>
		<category><![CDATA[芯金製作+ゴム加工]]></category>
		<category><![CDATA[製品紹介]]></category>
		<category><![CDATA[ウレタン]]></category>
		<category><![CDATA[ゴムローラー]]></category>
		<category><![CDATA[工業用]]></category>
		<category><![CDATA[搬送]]></category>
		<category><![CDATA[溝加工]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6230</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3.jpg" class="webfeedsFeaturedVisual" /></p>【ヘリカル溝加工付き】小型ウレタンローラー 中部地方のお客様から、大型のゴムローラー巻き替え依頼をいただきました。 ウレタンゴム材質のローラー表面には「ヘリカル溝加工」を施したいというご要望。 小サイズ品のため、意外と1 [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-1.jpg" alt="" class="wp-image-6231" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ヘリカル溝加工付きのウレタンローラー</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>小型ゴムローラーの巻替えをご検討中の方</li>



<li>ゴムローラー表面にヘリカル溝加工できる業者をお探しの方</li>



<li>近隣にゴムローラー発注先がなく、お困りの方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">【ヘリカル溝加工付き】小型ウレタンローラー</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>中部地方のお客様から、大型のゴムローラー巻き替え依頼をいただきました。</p>



<p>ウレタンゴム材質のローラー表面には「ヘリカル溝加工」を施したいというご要望。</p>



<p>小サイズ品のため、意外と1点物で小さいサイズを受けてくれる業者も多くありません。</p>



<p>当社では小さいサイズの製品も1点からお受けし、お客様のご要望に添った内容の材質・加工品をご提供できるように心がけています。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>下の写真の小型ウレタンゴムローラーの巻替えと溝加工を1点だけお願いしたいのですが、ご対応可能でしょうか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<figure class="wp-block-image size-medium"><img decoding="async" width="300" height="225" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-2-300x225.jpg" alt="" class="wp-image-6232" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-2-240x180.jpg 240w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-2.jpg 640w" sizes="(max-width: 300px) 100vw, 300px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知致しました。<br>修繕・巻替えが必要な中古ロールを当社にお送りいただくことは可能ですか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>硬度は分かりません。それと溝も中古ローラーと同じような加工は可能ですか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>ありがとうございます。<br>それでは、中古ローラーを荷受けしましたら、硬度は中古品を測定して近い硬度をご提案させていただきます。<br>溝加工についても図面がない場合は全く同じにはできませんが、見本となる中古ローラーに合わせて近い内容の加工にて対応致します。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「&nbsp;小型ウレタンローラー ヘリカル溝加工付き 」</strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3.jpg" alt="" class="wp-image-6234" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-3-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：仕上径φ36.5mm×芯径φ30×ゴム幅78mm L</li>



<li>材質：ウレタン</li>



<li>硬度：90度</li>



<li>ヘリカル溝加工 13本 左45度 溝幅2mm・溝深2mm</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様からゴム巻替えが必要な中古ローラーを当社に送っていただき、そのゴムローラーを新しくゴム巻きし、溝加工しました。</p>



<p>小型のローラーのため特に指定のヘリカル溝加工は加工技術が必要です。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">ゴム巻替え ビフォーアフター</h4>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-4.jpg" alt="" class="wp-image-6236" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-4.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-4-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-4-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「前」</figcaption></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-5.jpg" alt="" class="wp-image-6235" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-5.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-5-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-5-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「後」</figcaption></figure>
</div>
</div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">製作納期</h4>



<p>ゴム巻替え+溝切加工で約1ヵ月程度。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">ゴム巻きが必要な中古ローラーを送っていただく</h3>



<h4 class="wp-block-heading">中古ロールを溝の形状見本としても活用</h4>



<p>お客様がロールの図面をお持ちではなかったため、溝の形状や硬度は見本となる中古ロールから確認させていただきました。<br></p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-6.jpg" alt="" class="wp-image-6237" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-6.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-6-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-6-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">支給いただいた中古ロール</figcaption></figure>
</div>
</div>



<p class="is-style-icon_pen">当社での荷受けは土日祝日でも可能なため、お客様のご都合が良いタイミングで発送下さい。</p>



<h4 class="wp-block-heading">硬度が分からなければ当社で測定致します。</h4>



<p>お客様によるとご利用中のゴムローラーの硬さ(硬度)が不明とのことでしたので、見本ロールをお預かりして当社にて見本品の硬度を計測させていただきました。</p>



<p>見本品は90度近く硬度がありましたので、近似値の90度ウレタン材質にてご提案しました。</p>



<p class="is-style-big_icon_memo"><span class="swl-marker mark_yellow">ご利用用途から最適な硬度をご提案することも可能</span>ですので、お問合せの際は、情報を頂戴できますと幸いです。</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">溝の形状についてご注文方法</h3>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-7.jpg" alt="" class="wp-image-6238" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-7.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-7-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-7-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>ヘリカル溝ゴムローラーをご注文の際には、<span class="swl-marker mark_yellow">「らせんの角度と溝の本数」をご指示下さい。</span></p>



<p>「らせんの角度と溝の本数」について指示が難しければ、できるだけ中古品現物と同じような内容で加工・仕上を行います。</p>



<p class="is-style-icon_info">中古品現物に合わせる場合は、中古品現物と新品の「角度・深さ」を完全一致させることは出来かねますので、あらかじめご了承下さいませ。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="is-style-balloon_box">参考記事 / 溝切加工の種類</p>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2020/10/Roller-grooving-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/roller-grooving/">溝切加工の種類 | ゴムローラー 表面加工</a>
						<span class="p-blogCard__excerpt">スパイラル溝切加工を施した樹脂ロール こんな方におすすめ ゴムローラーの表面に溝切加工を施したいとお考えの方 溝切加工の種類についてお調べの方 溝切加工の機能・&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">芯金からの複製も可能</h3>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-8.jpg" alt="" class="wp-image-6239" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-8.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-8-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/09/small-urethane-roller-with-helical-grooves-8-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様の元で予備のロールが無いなど、ローラーの複製をお求めの場合は、芯金複製も対応可能です。</p>



<p>その場合も、図面か見本となる中古ロールが必要となりますので、ご協力をお願いします。</p>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>芯金複製の場合、必要なもの</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>ロールの図面 (特に芯金部の材質や寸法記載のもの・)</li>



<li>見本となる中古ロール (中古ロールは図面作成のためにしばらくお借りします。)</li>
</ol>
</div></div>



<p class="is-style-icon_info">芯金部の金属指定がない場合は、近い材質でご提案となります。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/small-urethane-roller-with-helical-grooves/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>2025年 夏期休業のお知らせ</title>
		<link>https://www.nakajima-roller.jp/notice-of-summer-vacation/</link>
					<comments>https://www.nakajima-roller.jp/notice-of-summer-vacation/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Thu, 31 Jul 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[お知らせ]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=3931</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2022/08/notice-of-summer-vacation-in-2022-eye.jpg" class="webfeedsFeaturedVisual" /></p>&#160; 平素は当社の製品・サービスをご利用いただきありがとうございます。 誠に勝手ながら下記の期間、休業とさせて頂きますので、ご案内申し上げます。 お客様にはご不便をおかけいたしますが、何卒ご了承くださいますようお [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2022/08/notice-of-summer-vacation-in-2022-eye.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image is-style-st-photohu"><img decoding="async" width="640" height="427" src="https://www.nakajima-roller.jp/wp-content/uploads/2022/08/notice-of-summer-vacation-in-2022.jpg" alt="" class="wp-image-3936" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2022/08/notice-of-summer-vacation-in-2022.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2022/08/notice-of-summer-vacation-in-2022-300x200.jpg 300w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">2024年 夏期休業のお知らせ</figcaption></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>&nbsp; 平素は当社の製品・サービスをご利用いただきありがとうございます。 </p>



<p>誠に勝手ながら下記の期間、休業とさせて頂きますので、ご案内申し上げます。</p>



<p> お客様にはご不便をおかけいたしますが、何卒ご了承くださいますようお願いいたします。 &nbsp;</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading"><strong>夏期休業期間</strong></h3>



<p class="has-border -border02">2025年8月9日（土）～2025年8月17日（日）  </p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading h3modoki"><strong>お問い合わせに関しまして</strong></h3>



<p>2025年8月8日（金）の営業終了後（17時半以降）のお問い合わせについては2025年8月18日（月）より順次対応させていただきます。</p>



<p><br> (メールやSNSのメッセージにて、お問い合わせいただいた場合、可能な限りは上記休業期間中でも返信をさせていただきます。) &nbsp; &nbsp;</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center is-style-balloon_box2 has-border -border01">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/notice-of-summer-vacation/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>【木材加工機】エンドレスサンドペーパー駆動用 ダブルヘリカル ゴムローラー</title>
		<link>https://www.nakajima-roller.jp/double-helical-rubber-roller-for-driving/</link>
					<comments>https://www.nakajima-roller.jp/double-helical-rubber-roller-for-driving/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Sun, 18 May 2025 23:30:00 +0000</pubDate>
				<category><![CDATA[ゴムローラー巻替え]]></category>
		<category><![CDATA[仕様]]></category>
		<category><![CDATA[特注品]]></category>
		<category><![CDATA[製品紹介]]></category>
		<category><![CDATA[NBR]]></category>
		<category><![CDATA[ゴムローラー]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6136</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1.jpg" class="webfeedsFeaturedVisual" /></p>【木材加工機】エンドレスサンドペーパー駆動用 ダブルヘリカル ゴムローラー 中部地方のお客様から、大型のゴムローラー巻き替え依頼をいただきました。 ゴムローラー表面には「ダブルヘリカル溝加工」が必要でした。 1本のローラ [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1.jpg" alt="" class="wp-image-6139" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-1-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ダブルヘリカル溝加工を施したゴムローラー</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M32 46.5H16c-1.1 0-2-.9-2-2s.9-2 2-2h16c1.1 0 2 .9 2 2s-.9 2-2 2zM33.3 18.6c-.7 0-1.3-.5-1.5-1.2-.7-3.2-3.2-5.7-6.4-6.3-.8-.1-1.4-.9-1.2-1.7s.9-1.4 1.7-1.2c4.4.8 8 4.2 8.9 8.6.2.8-.4 1.6-1.2 1.8h-.3z"></path><path d="M30 40.5H18c-2.2 0-4-1.8-4-4v-1.6c0-.6-.3-1.1-.8-1.5C8.4 29.8 5.7 24 6 18c.5-9.1 8-16.6 17.1-17C29 .8 34.5 3.2 38.2 8c1.8 2.3 3 5.1 3.5 7.9 1.1 6.8-1.5 13.3-6.9 17.4-.6.4-.9 1-.9 1.7v1.5c.1 2.2-1.7 4-3.9 4zM23.3 5c-7.1.3-12.9 6.2-13.3 13.2-.2 4.7 1.8 9.1 5.6 11.9 1.5 1.1 2.4 2.9 2.4 4.7v.6c0 .6.4 1 1 1h10c.6 0 1-.4 1-1V35c0-1.9.9-3.7 2.5-4.8 4.3-3.2 6.3-8.5 5.3-13.9-.4-2-1.2-3.8-2.4-5.4-3-4-7.4-6.1-12.1-5.9z"></path></svg><span>こんな方におすすめ</span></div><div class="cap_box_content">
<div class="wp-block-group"><div class="wp-block-group__inner-container">
<ul class="wp-block-list -list-under-dashed">
<li>大型ゴムローラーの巻替えをご検討中の方</li>



<li>ゴムローラー表面にダブルヘリカル溝加工できる業者をお探しの方</li>



<li>近隣にゴムローラー発注先がなく、お困りの方</li>
</ul>
</div></div>
</div></div>



<h2 class="wp-block-heading has-text-align-center">【木材加工機】エンドレスサンドペーパー駆動用 <br>ダブルヘリカル ゴムローラー</h2>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>中部地方のお客様から、大型のゴムローラー巻き替え依頼をいただきました。</p>



<p>ゴムローラー表面には「ダブルヘリカル溝加工」が必要でした。</p>



<p>1本のローラーですが、大人が一人で抱えて持てないぐらい重量があります。</p>



<p>本ページでは、製品仕様はもちろんのこと、お客様とのやりとり・取引手順を含めて、注文から納品までの流れをご参考にしていただけるように作成致しました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">お客様のご要望</h3>


<p>中部地方の製造業者です。<br>エンドレスサンドペーパー機の駆動用ゴムローラーの巻替えと溝付けをお願いしたいです。<br>会社近隣でゴムローラー溝加工をお願いできる業者が無いため、困っています。<br>見積りと納期を教えていただくことは可能でしょうか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>承知致しました。<br>修繕・巻替えが必要な中古ロールを当社にお送りいただくことは可能ですか？</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>分かりました。<br>木製の架台に中古ローラーを固定して貴社へ発送します。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>ありがとうございます。<br>それでは、ローラーの巻き替え・溝切加工完了後に貴社に用意していただいた木製の架台を使ってご返送させていただきます。<br>まずはお見積りの金額と納期を確認いただき、ご検討下さいませ。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">製品の仕様</h3>



<div class="swell-block-capbox cap_box" data-colset="col3"><div class="cap_box_ttl"><span><strong>「<strong>&nbsp;エンドレスサンドペーパー駆動用ローラー 」</strong></strong></span></div><div class="cap_box_content">
<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-2.jpg" alt="" class="wp-image-6161" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-2.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-2-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/double-helical-rubber-roller-for-driving-2-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<ul class="wp-block-list -list-under-dashed">
<li>サイズ：直径295mm×ゴム幅460mm L</li>



<li>材質：NBR黒</li>



<li>硬度：45度</li>



<li>ダブルヘリカル溝加工</li>
</ul>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>お客様からゴム巻替えが必要な中古ローラーを当社に送っていただき、そのゴムローラーを新しくゴム巻きし、溝加工しました。</p>



<p>重量がある大型ローラーのため、お客様からの発送の際は、木製の架台をご用意いただき、その架台に乗せて完成品を返送させていただきました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">ゴム巻替え ビフォーアフター</h4>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-5.jpg" alt="" class="wp-image-6181" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-5.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-5-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-5-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「前」</figcaption></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-6.jpg" alt="" class="wp-image-6182" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-6.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-6-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-6-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">ゴム巻替え「後」</figcaption></figure>
</div>
</div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">製作納期</h4>



<p>ゴム巻替え+溝切加工で約2ヵ月程度かかりました。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">ゴム巻きが必要な中古ローラーを送っていただく</h3>



<h4 class="wp-block-heading">ローラー運搬用の架台を活用</h4>



<p>本案件のお客様は中部地方の企業様。<br>東京にある当社から引取にお伺いすることができないため、先方様から当社に修理が必要な中古ロールを送っていただきました。<br>重量があり大型のロールでしたが、お客様の方で運搬用の架台をご用意いただき、ローラーを下の写真のように固定して発送して下さいました。</p>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-3.jpg" alt="" class="wp-image-6184" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-3.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-3-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-3-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-4.jpg" alt="" class="wp-image-6185" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-4.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-4-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-4-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>
</div>
</div>



<p class="is-style-icon_pen">当社での荷受けは土日祝日でも可能なため、お客様のご都合が良いタイミングで発送下さい。</p>



<h4 class="wp-block-heading">ご指定の配送業者にて手配可能</h4>



<p>本件のユーザー様が日頃ご利用の配送業者様にて完成品を発送手配させていただきました。</p>



<p>本件は着払いにて、お客様に送料をご負担いただいております。</p>



<p class="is-style-big_icon_memo">大型ロールは「ヤマト宅急便」などのサービスでサイズ・重量超過となり発送できないことがございますので、送り方についてもお打合せが必要です。</p>



<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">溝の形状についてご注文方法</h3>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-7.jpg" alt="" class="wp-image-6187" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-7.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-7-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-7-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>ダブルヘリカル溝ゴムローラーをご注文の際には、<span class="swl-marker mark_yellow">「らせんの角度と溝の本数」をご指示下さい。</span></p>



<p>「らせんの角度と溝の本数」について指示が難しければ、できるだけ中古品現物と同じような内容で加工・仕上を行います。</p>



<p class="is-style-icon_info">中古品現物に合わせる場合は、中古品現物と新品の「角度・深さ」を完全一致させることは出来かねますので、あらかじめご了承下さいませ。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="is-style-balloon_box">参考記事 / 溝切加工の種類</p>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2020/10/Roller-grooving-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/roller-grooving/">溝切加工の種類 | ゴムローラー 表面加工</a>
						<span class="p-blogCard__excerpt">スパイラル溝切加工を施した樹脂ロール こんな方におすすめ ゴムローラーの表面に溝切加工を施したいとお考えの方 溝切加工の種類についてお調べの方 溝切加工の機能・&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading"><strong>金属ロール部分の錆止め処理</strong></h3>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="480" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-8.jpg" alt="" class="wp-image-6188" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-8.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-8-300x225.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2025/05/double-helical-rubber-roller-for-driving-8-240x180.jpg 240w" sizes="(max-width: 640px) 100vw, 640px" /><figcaption class="wp-element-caption">金属部分は錆止め処理を施しています</figcaption></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p>ゴムローラーの金属部分がむき出しの箇所は、錆止め防止処理の塗装を行っています。</p>



<p>本件は金属がむき出しの部分を「金ニス」で塗装し防錆処理しています。</p>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>防錆処理の例</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>金ニス塗装</li>



<li>黒ペイント塗装</li>
</ol>
</div></div>



<p class="is-style-icon_info">防錆処理は基本的にサービスになるため、特定の方法を指定いただくことはできません。<br>ゴムローラーの種類によっては防錆処理を行わない場合もございますので、ご了承下さい。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2019/08/rubber-roller-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller/">ゴムローラーとは？用途・材質・加工・注文方法まで徹底解説</a>
						<span class="p-blogCard__excerpt">印刷機用のゴムローラー こんな方におすすめ 当社で、どのようなゴムローラーを製造できるか確認されたい方 ゴムローラーはどのような種類があるのか知りたい方 ゴムロ&#8230;</span>					</div>
				</div>
			</div>
		</div>

<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2021/08/product-information-page-by-application-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/product-information-page-by-application/">ゴムローラー 用途別 製品ご案内ページ</a>
						<span class="p-blogCard__excerpt">ご利用用途別 ローラー製品ご紹介ページへようこそ！ インクやニスを使う用途( 版画・印刷・塗装・コーターローラー ) 本ページでは、ローラーの用途ごとにお役に立てそ&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center has-border -border01 is-style-balloon_box2">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/double-helical-rubber-roller-for-driving/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
		<item>
		<title>【お知らせ】NEW平版ゴムローラー 最大15％OFFセール実施</title>
		<link>https://www.nakajima-roller.jp/new-lithography-rubber-roller-on-sale/</link>
					<comments>https://www.nakajima-roller.jp/new-lithography-rubber-roller-on-sale/#respond</comments>

		<dc:creator><![CDATA[nakajima-roller]]></dc:creator>
		<pubDate>Wed, 30 Apr 2025 08:56:52 +0000</pubDate>
				<category><![CDATA[お知らせ]]></category>
		<guid isPermaLink="false">https://www.nakajima-roller.jp/?p=6163</guid>

					<description><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/sale.jpg" class="webfeedsFeaturedVisual" /></p>NEW平版ゴムローラー 最大15％OFFセール実施 平素は格別のご愛顧を賜り、厚く御礼申し上げます。 5/1(木)～5/31(金)の1ヵ月間、NEW平版ゴムローラーの割引セールを実施致します。 セール実施期間 2025年 [&#8230;]]]></description>
										<content:encoded><![CDATA[<p><img src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/sale.jpg" class="webfeedsFeaturedVisual" /></p>
<figure class="wp-block-image size-large is-style-photo_frame"><img decoding="async" width="1024" height="768" src="https://www.nakajima-roller.jp/wp-content/uploads/2020/03/IMG_0453-1024x768.jpg" alt="" class="wp-image-1018"/><figcaption class="wp-element-caption">NEW平版ゴムローラー 各種</figcaption></figure>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h2 class="wp-block-heading has-text-align-center">NEW平版ゴムローラー 最大15％OFFセール実施</h2>



<p>平素は格別のご愛顧を賜り、厚く御礼申し上げます。</p>



<p>5/1(木)～5/31(金)の1ヵ月間、NEW平版ゴムローラーの割引セールを実施致します。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>


<p>NEW平版ゴムローラーの購入をご検討中の方は、この機会に是非、お買い求め下さい！</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">セール実施期間</h3>



<figure class="wp-block-image size-full"><img decoding="async" width="640" height="427" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/sale.jpg" alt="" class="wp-image-6164" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/sale.jpg 640w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/sale-300x200.jpg 300w" sizes="(max-width: 640px) 100vw, 640px" /></figure>



<p class="has-border -border02">2025年5月1日（木） ～ 2025年5月31日（金）&nbsp;</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">セール対象製品</h3>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>セールの割引率</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-good_list">
<li>NEW平版ゴムローラー 中質30度品 各種 ＝ 10％OFF</li>



<li>NEW平版ゴムローラー 軟質20度品＆硬質45度品 各種 ＝ 15％OFF</li>
</ol>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">定価より10％OFFの製品</h4>



<figure class="wp-block-image size-full is-style-photo_frame"><img decoding="async" width="888" height="888" src="https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317.jpg" alt="" class="wp-image-2192" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317.jpg 888w, https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317-300x300.jpg 300w, https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317-768x768.jpg 768w, https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317-150x150.jpg 150w, https://www.nakajima-roller.jp/wp-content/uploads/2020/04/IMG_0317-100x100.jpg 100w" sizes="(max-width: 888px) 100vw, 888px" /><figcaption class="wp-element-caption">NEW平版ゴムローラー 中質30度品 各種</figcaption></figure>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>【定価より10％OFF】NEW平版ゴムローラー 中質30度品</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>NEW平版ゴムローラー φ11cm×27cm (中質30°)</li>



<li>NEW平版ゴムローラー φ11cm×30cm (中質30°)</li>



<li>NEW平版ゴムローラー φ11cm×36cm (中質30°)</li>



<li>NEW平版ゴムローラー φ11cm×40cm (中質30°)</li>



<li>NEW平版ゴムローラー φ11cm×50cm (中質30°)</li>



<li>NEW平版ゴムローラー φ11cm×60cm (中質30°)<br></li>



<li>NEW平版ゴムローラー φ17cm×40cm (中質30°)</li>



<li>NEW平版ゴムローラー φ17cm×50cm (中質30°)</li>



<li>NEW平版ゴムローラー φ17cm×60cm (中質30°)</li>
</ol>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">定価より15％OFFの製品</h4>



<div class="wp-block-columns">
<div class="wp-block-column">
<figure class="wp-block-image size-full is-style-photo_frame"><img decoding="async" width="550" height="550" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/soft-roller.jpg" alt="" class="wp-image-6165" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/soft-roller.jpg 550w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/soft-roller-300x300.jpg 300w" sizes="(max-width: 550px) 100vw, 550px" /><figcaption class="wp-element-caption">NEW平版ゴムローラー軟質20度品</figcaption></figure>
</div>



<div class="wp-block-column">
<figure class="wp-block-image size-full is-style-photo_frame"><img decoding="async" width="550" height="550" src="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/hard-roller.jpg" alt="" class="wp-image-6166" srcset="https://www.nakajima-roller.jp/wp-content/uploads/2025/04/hard-roller.jpg 550w, https://www.nakajima-roller.jp/wp-content/uploads/2025/04/hard-roller-300x300.jpg 300w" sizes="(max-width: 550px) 100vw, 550px" /><figcaption class="wp-element-caption">NEW平版ゴムローラー硬質45度品</figcaption></figure>
</div>
</div>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>【定価より15％OFF】NEW平版ゴムローラー 軟質20度品</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>NEW平版ゴムローラー φ11cm×27cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ11cm×30cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ11cm×36cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ11cm×40cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ11cm×50cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ11cm×60cm (軟質20°)<br></li>



<li>NEW平版ゴムローラー φ17cm×40cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ17cm×50cm (軟質20°)</li>



<li>NEW平版ゴムローラー φ17cm×60cm (軟質20°)</li>
</ol>
</div></div>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col1"><div class="cap_box_ttl"><span>【定価より15％OFF】NEW平版ゴムローラー 硬質45度品</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>NEW平版ゴムローラー φ11cm×27cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ11cm×30cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ11cm×36cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ11cm×40cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ11cm×50cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ11cm×60cm (硬質45°)<br></li>



<li>NEW平版ゴムローラー φ17cm×40cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ17cm×50cm (硬質45°)</li>



<li>NEW平版ゴムローラー φ17cm×60cm (硬質45°)</li>
</ol>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">【注意】セール対象外の製品</h3>



<p>アルミ持ち手タイプの平版ゴムローラー、ゴム手ローラーなど<br>「NEW平版ゴムローラー」以外の製品はセール対象外です。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h3 class="wp-block-heading">ご注文方法 / ECサイトよりご注文下さい</h3>



<h4 class="wp-block-heading">ご注文はECサイトからどうぞ</h4>



<p>当社ECカート販売サイトの商品ページからご注文いただくことが可能です。</p>



<p>下記のURLリンクより、アクセスいただけます。</p>



<div class="swell-block-capbox cap_box is-style-onborder_ttl2" data-colset="col1"><div class="cap_box_ttl"><span><strong>ご注文は下記のURLリンクよりどうぞ</strong></span></div><div class="cap_box_content">
<p><a href="https://nakajima-roller.shop-pro.jp/?mode=cate&amp;cbid=2555726&amp;csid=0">https://nakajima-roller.shop-pro.jp/?mode=cate&amp;cbid=2555726&amp;csid=0</a></p>
</div></div>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">割引方法 / クーポン</h4>



<p>ECサイト内で、ご購入商品をカートに追加していただき、お客様情報を入力、画面下にクーポンコード入力欄がございますので、そちらに以下のクーポンコードをご入力下さい。</p>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col3"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M43 46H21c-1.1 0-2-.9-2-2s.9-2 2-2h22c1.1 0 2 .9 2 2s-.9 2-2 2zM28.6 10.6l2.5-4.3c.3-.5.1-1.1-.4-1.4l-5.2-3c-.5-.3-1.1-.1-1.4.4l-2.5 4.3 7 4zM20.2 9.2 3.3 38.5c-.4.7-.6 1.5-.5 2.3l.3 4.5c0 .7.8 1.1 1.4.8l4-2c.7-.4 1.3-.9 1.7-1.6l16.9-29.3-6.9-4z"></path></svg><span>【定価より10％OFF】クーポンコード</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>「NR10OFF」</li>
</ol>
</div></div>


<p>10％割引は、NEW平版ゴムローラー 中質30度品が対象です。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<div class="swell-block-capbox cap_box is-style-onborder_ttl" data-colset="col3"><div class="cap_box_ttl" data-has-icon="1"><svg height="1em" width="1em" xmlns="http://www.w3.org/2000/svg" aria-hidden="true" viewBox="0 0 48 48"><path d="M43 46H21c-1.1 0-2-.9-2-2s.9-2 2-2h22c1.1 0 2 .9 2 2s-.9 2-2 2zM28.6 10.6l2.5-4.3c.3-.5.1-1.1-.4-1.4l-5.2-3c-.5-.3-1.1-.1-1.4.4l-2.5 4.3 7 4zM20.2 9.2 3.3 38.5c-.4.7-.6 1.5-.5 2.3l.3 4.5c0 .7.8 1.1 1.4.8l4-2c.7-.4 1.3-.9 1.7-1.6l16.9-29.3-6.9-4z"></path></svg><span>【定価より20％OFF】クーポンコード</span></div><div class="cap_box_content">
<ol class="wp-block-list is-style-check_list">
<li>「NR15OFF」</li>
</ol>
</div></div>


<p>15％割引は、NEW平版ゴムローラー 軟質20度＆硬質45度品が対象です。</p>
<span class="c-balloon__shapes"><span class="c-balloon__before"></span><span class="c-balloon__after"></span></span></div></div></div></div>


<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<h4 class="wp-block-heading">割引方法 / ご注文方法が分からない方</h4>



<p>ご注文方法・クーポン使用方法が分からない方は、下の問い合わせフォームより、気軽にお申し付け下さい。</p>



<div style="height:10px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="is-style-balloon_box">白ゴム品はさらにお得に購入できます！</p>


<div class="swell-block-postLink">			<div class="p-blogCard -internal" data-type="type1" data-onclick="clickLink">
				<div class="p-blogCard__inner">
					<span class="p-blogCard__caption">あわせて読みたい</span>
					<div class="p-blogCard__thumb c-postThumb"><figure class="c-postThumb__figure"><img decoding="async" src="https://www.nakajima-roller.jp/wp-content/uploads/2024/02/rubber-roller-products-available-at-great-prices-eye.jpg" alt="" class="c-postThumb__img u-obf-cover" width="320" height="180"></figure></div>					<div class="p-blogCard__body">
						<a class="p-blogCard__title" href="https://www.nakajima-roller.jp/rubber-roller-products-available-at-great-prices/">【訳アリ/在庫のみ】お得に買えるゴムローラー製品</a>
						<span class="p-blogCard__excerpt">こんな方におすすめ 硬質ゴムローラーをお求めの方 当社のゴムローラー製品を少しでも安く購入したい方 通常製造品とは違った仕様の製品に興味がある方 【訳アリ/在庫の&#8230;</span>					</div>
				</div>
			</div>
		</div>


<div style="height:30px" aria-hidden="true" class="wp-block-spacer"></div>



<p class="has-text-align-center is-style-balloon_box2 has-border -border01">お問い合わせはコチラからどうぞ</p>



<p class="has-text-align-center"><iframe style="height: 500px; max-width: 620px; width: 100%; border: 0;" src="https://ws.formzu.net/dist/S58786040/"></iframe></p>
]]></content:encoded>

					<wfw:commentRss>https://www.nakajima-roller.jp/new-lithography-rubber-roller-on-sale/feed/</wfw:commentRss>
			<slash:comments>0</slash:comments>


			</item>
	</channel>
</rss>
